Ethernet "Lightning" Protection

PoE Configuration
PoE Data Pins
PoE Power Pins
Max. POE operating Voltage
Surge Handling

Passive (Positive or Negative power supply)
1, 2, 3, 6
4, 5, 7, 8
Up to 57V
8/20uS (10kA)*

*The miniPCI card should be properly grounded with the supplied cable to achieve this level of protection.

---

Miscellaneous

Dimensions
Weight
Operational Temperature
Storage Temperature
Humidity
Included Accessories

Warranty

5.8 cm X 3 cm (2.3 inch X 1.17 inch)
22 grams (0.78 ounces)
-40C to +80C
-40C to +80C
0% to 95% (non-condensing)
15cm ground wire, 1 screw (4mm length for wire), 2 screws (5mm length to attach to PRO cards), 1 nut
One Year Limited Warranty
